Industrial Ethernet FastConnect stripping tool, Stripping tool for fast stripping of the IE FastConnect cables SIMATIC NETIE FastConnect Stripping Tool
Mounting kit, can only be used in connection with SCALANCE W-786 scope of delivery: Adapter for wall mounting, Adapter for S7-300 busbar, Adapter for 35 mm DIN rail, clamps for mast mounting, operating instructions, German/English
Industrial Ethernet FastConnect TP standard cable GP 4x 2, TP installation CAT6A cable for connection to IE FC RJ45 plug 4x 2, AWG24, sold by the meter, delivery unit max. 2000 m minimum order quantity 20 m. SIMATIC NET IE FC TP Standard Cable GP 4x2 (AWG 24, Type C)Cable for Gigabit-capable cabling...
Dane techniczne
Dopuszczalna temperatura otoczenia kabla po montażu (bez wibracji)
-40 - 85 °C
Dopuszczalna temperatura otoczenia kabla podczas montażu
-40 - 80 °C
Liczba skrętek
4
Liczba żył
8
Min. dopuszczalny promień zginania w instal. ruchomych bez prowadzenia
40 mm
Min. dopuszczalny promień zginania w instal. ruchomych z wymuszonym prowadzeniem
40 mm
Min. dopuszczalny promień zginania w instalacjach stałych
Mounting kit for ANT795-6MN Mounting aid for installation of ANT795-6MN below roof, IP20 (-40-+70 °C), Scope of delivery: 1 mounting aid 1 elbow adapter N-Connect male/female 2 fixing screws Compact instructions as hard copy German/English. SIMATIC NETIWLAN mounting aid for antenna ANT795-6MN
C-plug, removable data storage medium For simple device replacement in case of fault, for recording configuration or engineering and application data, can be used in the following SIMATIC NET products with C-plug slot: SCALANCE XC-200, XP-200, XM-400, XR-500, M-800, W-700, SC-600 and S615. SCALANCE C-PLUG
ANT795-6DC IWLAN antenna with weak directional effect; incl. N-female plug: 9 dBi; IP66/67 (-40-+80 °C), 2.4/5GHz; Wi-Fi compliance and observe national approvals; mounting on wall or mast compact instructions as hard copy German/English; scope of delivery: 1x ANT795-6DC, 1x mounting aid for alignment...
ANT792-4DN IWLAN antenna for RCoax systems, 4 dBi Helix antenna, circular polarizing clockwise; incl. N-female plug IP65 (-40-+70 °C), 2.4 GHz, SCALANCEAntennaRCoax Antenna ANT792-4DNUse in combination with a coaxial cable, in environments in which stations move within limited areas or exclusively along...
ANT792-8DN IWLAN antenna with strong directional effect incl. N-female plug: 14 dBi, IP23, outdoor, (-40-+70 °C); 2.4 GHz, Wi-Fi compliance observe national approvals; mounting on wall or mast, compact instructions as hard copy German/English, scope of delivery: 1x ANT792-8DN, 1x mounting aid for alignment...
ANT793-4MN IWLAN antenna for RCoax systems; Lambda/4 with omnidirectional Characteristic, 6 dBi incl. N-female plug IP65 (-40-+70 °C), 5 GHz. SCALANCEAntennaRCoax Antenna ANT793-4MNUse in combination with a coaxial cable, in environments in which stations move within limited areas or exclusively along...
ANT795-4MA IWLAN antenna with omnidirectional Characteristic, Radially rotatable, with additional joint, incl. RSMA connector: 3/5 dBi, IP30 (-20-+60 °C), 2.4/5 GHz; Wi-Fi compliance and Observe national approvals; Direct mounting on SCALANCE W with RSMA connection system; scope of delivery: 1x ANT795-4MA...
ANT795-4MB IWLAN antenna with omnidirectional Characteristic, Radially rotatable, with additional joint, incl. RSMA connector: 2/3 dBi, IP65 (-20-+60 °C), 2.4/5 GHz; Wi-Fi compliance and national approvals to be observed; direct mounting on SCALANCE W with RSMA connection system; scope of delivery:...
