Stycznik modułowy serii iCT, o numerze A9C21864, iCT50r-63-40-230, napięcie sterowania 220/240 VAC 50Hz, 4 styki zwierne, prąd znamionowy AC7A: 63 A, do sterowania obwodami elektrycznymi. Wyposażony w dźwignię ręcznego sterowania Załączony-Auto-Wyłączony pozwalający na lokalne sterowanie. enterOptyczny wskaźnik st anu styków wyjściowych, możliwość rozbudowy o styki pomocnicze
Dane techniczne
Głębokość wbudowania
43.5 mm
Kategoria użytkowania
7
Liczba modułów
3
Liczba styków rozwiernych
0
Liczba styków zwiernych
4
Liczba styków zwiernych
4
Maksymalna zdolność łączeniowa dla świetlówek
11550 VA
Maksymalna zdolność łączeniowa dla świetlówek (kompensacja DUO)
17700 VA
Maksymalna zdolność łączeniowa dla świetlówek (z kompensacją równoległą)
This Acti 9 iATEt is reliable time delay auxiliary. It operates from 24VAC to 240VAC and 24VDC to 110VDC control voltage. Mounting is performed on the left of iTL impulse relay or iCT contactor with yellow clips. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. 5 time...
This Acti 9 iACT24 is reliable control and indication auxiliary. It has 1 normally open signal contact. Control voltage is 24VDC and 230V AC. Mounting is performed on the left of Acti9 iCT contactors with operational current less than or equal to 25A. The degree of protection is IP20 and IP40 in an enclosure...
This Acti 9 iACTc is modular and reliable double control input auxiliary. Rated supply voltage is 220VAC to 240VAC and control voltage is 230VAC to 240VAC. Mounting is performed on the left of Acti9 iCT contactors. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. It...
This Acti 9 iACTp is modular and reliable overvoltage protection auxiliary (2 circuits). It operates from 220VAC to 240VAC, at a frequency of 50/60 Hz. Mounting is performed on the left of Acti9 iCT contactors. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. it si...
Ten Acti9 iACT jest niezawodnym zdalnym sygnalizatorem pomocniczym. Posiada 1 otwarty i zamknięty 1 styk, działa od 24VAC do 240VAC i 24VDC do 130VDC. Montaż odbywa się po prawej stronie styczników Acti9 iCT. Stopień ochrony w obudowie wynosi IP20 i IP40. Można go zamontować na szynie DIN. Jest...
This Acti 9 iACTs is reliable remote indication auxiliary. It has 2 normally open contacts, it operates from 24VAC to 240VAC and 24VDC to 130VDC. Mounting is performed on the right of Acti9 iCT contactors. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. It is compatible...
This Acti 9 iACTs is reliable remote indication auxiliary. It has 1 changeover contact, it operates from 24VAC to 240VAC and 24VDC to 130VDC. Mounting is performed on the right of Acti9 iCT contactors. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. It is compatible...
This is a set 20 screw shields. set of 10 dedicate to cover the upstream terminals and set of 10 for downstream terminals. It is compatible with 3P and 4P Acti9 iCT Contactor with a rated current 40A or 63A
This set of 10 Acti 9 electrical accessories it is dedicated to ensure the mechanical and/or electrical link. it is mounting between Acti9 iCT contactors or iTL impulse relays and their auxiliaries
