The XMP switches are electromechanical pressure switches for control circuits. They are used to control the pressure of air, fresh water and sea water from 0°C to +70°C. This IP54 pressure switch with an adjustable differential is intended for regulation between 2 thresholds. This switch includes a bare case without decompression valve. This pressure switch has an ajustable range of switching point (or rising pressure) of 1bar to 6bar (14.5psi to 87psi). It features 3 NC contacts, one G 3/8 female fluid connection and 2 entries incorporating n°13 plastic cable gland for electrical connection. The case is composed of polyamide impregnated with fibreglass. The entry in contact with fluids is made of chromated zinc alloy and the diaphragm of canvas covered nitrile. This pressure switch weighs 0.450kg. Pressure switches XMP are intended for power circuits (direct switching), with an adjustable differential. This product is certified by EAC. It meets CE and EN/IEC 60947-4-1 standards. Dedicated accessories, to be ordered separatly, are available to facilitate the setting of the switch. Knurled adjustment knob, fixing bracket, 13P cable glands, diaphragms, etc. It operates in all positions. The XMP range brings high level of reliability and quality, long life duration, and a worldwide availability. The line of XM pressure sensors and switches (formerly known as OsiSense) combine the latest pressure sensing technology with adaptability to virtually any configuration
