XCKN2127G11 ŁĄCZNIK KRAŃCOWY

The XCKN range is an offer of monolithic plastic limit switches dedicated to repetitive machines. The XCKN2127G11 limit switch is composed of a fixed plastic body and a plunger plastic head. The fixing is done by the body. It has a thermoplastic spring return roller lever plunger operator with a vertical approach (1 direction). The movement of operating head is linear. It has one normally closed and one normally open snap action contacts with positive opening operation. It has one cable entry tapped for Pg 11 cable gland and it is powered by screw-clamp terminals (clamping capacity : 1 x 0.34…2 x 1.5mm²). The contactor can perform an average of 10 million no-load operating cycles without mechanical failure. The XCKN2127G11 limit switch is made of a plastic body and a plastic head. It weighs 0.145kg and measures 96mm in height, 42.5mm in width, and 30mm in depth. This limit switch complies with UL, CSA, and CCC standards, and its protection level complies with IP65 (resistant to dust and water jets). Telemecanique Sensors limit switches are ideal for industrial environments : they are precise, robust, reliable, easy to install and offer high repeatability. A limit switch is a device that converts a mechanical motion into an electrical control signal
