The XCKP variable composition range is designed to offer the advantages of a metal head, high performance and world-wide availability through distribution. The XCKP2511G11 limit switch is composed of a fixed plastic body and a plunger zamak head. The fixing is done by the body. It has a metal spring return roller plunger with nitrile boot operator with a vertical approach (1 direction). The movement of operating head is linear. It has one normally closed and one normally open slow-break (break before make) contacts with positive opening operation. It has one cable entry tapped for Pg 11 cable gland and it is powered by screw-clamp terminals (clamping capacity : 1 x 0.5…2 x 2.5mm²). The contactor can perform an average of 15 million no-load operating cycles without mechanical failure. The XCKP2511G11 limit switch is made of a plastic body and a zamak head. It weighs 0.09kg and measures 65mm in height, 31mm in width, and 30mm in depth. It complies with UL, CSA, and CCC standards, and its protection level complies with IP66 and IP67 (resistant to dust, strong water jets, and water immersion). Telemecanique Sensors limit switches are ideal for industrial environments : they are precise, robust, reliable, easy to install and offer high repeatability. A limit switch is a device that converts a mechanical motion into an electrical control signal
